RF & Wireless

The Tech Between Us Podcast
RF & Wireless

Sponsor: Microchip Technology

Full Podcast (38:05mins)

Introduction (00:53mins)

Condensed Podcast (09:42mins)

Join us in our product technology conversation with Jason Tollefson of Microchip Technology as we discuss the difference between LoRa and LoRaWAN, LoRa network components and the applications utilizing this technology.

View more from Microchip Technology »

Podcast Host

Raymond Yin

Director of Technical Content, Mouser Electronics

Podcast Guest

Jason Tollefson

Microchip Technology

Harnessing LoRaWAN Technology for Good

Sponsor: Advantech

Blog: Harnessing LoRaWAN Technology for Good

BLOG: Harnessing LoRaWAN Technology for Good

LoRaWAN supports the U.N.'s efforts to make cities safe, resilient, and sustainable by transmitting data from wireless air-quality sensor networks to the Cloud. The data can be used to trigger measured and proactive interventions to reduce pollution and protect the health of the most vulnerable.

Read more »

View more from Advantech »



LoRa Technologies


LoRa spread spectrum modulation and LPWAN network protocol have combined forces to provide core long range capability with a cellular-like network

Fast Facts

  • LoRa uses sub-gigahertz radio frequency bands
  • Long range (7-10 KM)
  • Robust links for high capacity
  • Lower system cost
  • Extended battery lifetime
  • Geolocation (GPS-free, low-power tracking)
  • Secure
circular chart showing different technology ranges, LoRa 7-10 Range, Bluetooth 10m Range, WIFI 30 range, NARROW BAND FSK 16+ KM Range, Zigbee 300M Range.

Data Flow

In the LoRa network data flows from the application server to and from the end devices

Server icon

Application Server

IP to Network server to IP to Gateway
wifi signals
Icon of truck with location marker on it

Asset tracking

Icon of location Marker icon

Geolocation

Icon of electricity meter icon

Smart Meter

Icon of three wheat plants icon

Agriculture

Icon of Buildings with wifi symbol above

Buildings

Applications

Asset Tracking

Transmits location and additional data such as temperature, speed, and asset‑specific information

Smart Agriculture

Maximizes efficiency and reduces cost with little infrastructure or maintenance investment

Smart Meter

Offers an alternative to other connectivity for smart electricity metering solutions

diagram of end devices connect to gateway connect to the network then connects to the applications
Murata Logo

Integrated

LoRaWAN Modem

Ultra-small, long life modem for battery operated devices

Modem features ease of integration for
LoRaWAN IoT devices and applications.

Feature

  • AT-Command over UART for ease of use
  • LoRaWAN certified
  • Higher RF output power using SX1262
  • LoRa Alliance FUOTA support
  • Low power consumption
  • FCC/IC/CE “Reference” certified
  • LoRaWAN class A, B & C support

Benefits

  • Smallest/highly integrated LoRaWAN modem available in the market
  • Allows simple RF design with only Antenna attachment
  • Quick time to market LoRaWAN solution for Semtech SX1262 customers
  • Allows simple host MCU design as LoRaWAN stack is included in modem firmware
Cityscape with Smart agriculture, Energy Management, Smart bins, Smart Lighting, Smart Infrastructure, Traffic Control, Smart Factory, Smart Metering, Smart Parking, Icons above, all connecting to cloud computing icon.

View more from Murata »

More RF & Wireless

A square cube in the center of the image with signals coming from it

RF & Wireless Resources

Access additional RF & Wireless technical content from Mouser including articles, videos, eBooks and more.

Check it out »

Phone showing the sign-in screen for the Tech Quoitent game

What's your Tech Quotient?

Got answers? Well, we've got lots of technical questions and brainiac trivia to put your knowledge to the test. Beat the clock and see how you stack up against your friends, colleagues and other engineers around the globe.

Do you have the technical chops to triumph over all? Play now!

Get it on Google Play Download at the App Store

Google Play and the Google Play logo are trademarks of Google LLC.

Thank you to our supplier partners for their participation in helping us bring this content to our valued customers.
