Microchip Technology MEC1703 Embedded Controller

Microchip Technology MEC1703 Embedded Controller is a highly-configurable, mixed signal, advanced I/O controller customized for notebooks and industrial computing platforms. The MEC1703 incorporates a 32-bit features an Arm® Cortex^®-M4F Microcontroller core with a closely-coupled SRAM for code and data. A secure bootloader is used to download the custom firmware image from the system’s shared SPI Flash device, thereby allowing system designers to customize the device’s behavior.

Features

Arm® Cortex®-M4F processor core
Complete Arm-standard debug support
Comprehensive Arm-standard trace support
Internal memory of up to 480KB of SRAM
Enhanced Serial Peripheral Interface (eSPI) - Intel eSPI specification compliant
Supports LPC bus frequencies of 19MHz to 33MHz
Four EC-based SMBus 2.0 host controllers
Five independent hardware driven PS/2 ports
One quad Serial Peripheral Interface (SPI) controller
18 x 8 Interrupt capable multiplexed keyboard scan matrix

Four breathing/blinking LED interfaces
Multi-purpose AES cryptographic engine of hardware support for ECB, CTR, CBC and OFB AES modes
Cryptographic hash engine with support for SHA-1, SHA-256, SHA-512
Public key cryptographic engine with hardware support for RSA and elliptic curve public key algorithms and RSA keys length of 1024 or 2048 bits
True random number generator of 1K bit FIFO
Monotonic counter
RoHS compliant

The Microchip Technology MEC1703 Embedded Controller is available in WFBGA-144 and WFBFA-169 packages.
